| System Parameters | |
|---|---|
| Operation System | Linux |
| ROM / RAM | 32 MB / 256 MB |
| Processor | Embedded high performance processor |
| Video Parameters | |
| Lens | 1 |
| Resolution | Main stream: 1920 × 1080p, 720p; Sub stream: 640 × 480p |
| FOV | Horizontal: 131°, Vertical: 78° |
| WDR / Supplement | 120 dB / IR light up to 3m |
| Audio Parameters | |
| Audio Input/Output | Built-in omnidirectional microphone & loudspeaker |
| Audio Quality | Noise suppression and echo cancellation |
| Network & Interfaces | |
| Network Protocol | TCP/IP, RTSP, ipv6, onvif |
| Wi-Fi | IEEE802.11b/g/n |
| Device Interfaces | 1 RJ-45, 1 Tamper, 1 Exit Button, 1 RS-485, 1 Relay Lock Control |
| General | |
| Protective Level | IP65 |
| Dimensions | 138 mm × 65 mm × 27 mm |
| Power Supply | 12 VDC, Standard PoE |
