Tuya WiFi Smart Access Control Door Lock Waterproof Fingerprint Access Control System

Customization: Available
Card Reader Quantity: 2
Control Gates: One Gate

Product Description

Basic Info
Model NO.
ZDAC-2400W-WiFi
Technology
32-Bit Technology
Way of Control
Computer Control
Type
One-way Controller
Identification Way
Card, Pin, Card & Pin
Reading Distance
3-6cm
Operating Voltage
DC 12-24V
User Capacity
2000
Waterproof Design
IP68 / IP65
Material
Metal Case + Metal Keypad
Size
120* 58*20(mm)
ID Card Type
125kHz, EM
Product Description
Tuya WiFi Smart Access Control Door Lock Waterproof Fingerprint Access Control System

Aluminum alloy structure, Waterproof, fully potted, confirms to IP65, 125KHz EM and HID card for optional, Multi-function, 12P cable with built in door bell function, operating as slave reader, single door, anti-pass back, etc. Suitable for various occasions.

Tuya WiFi Smart Access Control
Key Features
  • Aluminium alloy case, waterproof, fully potted, meets IP-65 waterproof standard
  • Metal digital backlit keypad (Back light can be set Normal ON, Normal OFF or Human-Approach ON)
  • Built-in door bell key and built-in 125KHz card reader
  • 2000 users available, each has a card and a 4-6 digits password
  • Supports master card and 2-10 cards entry
  • Replay control to open, 1A
  • Wiegand 26-37 output card number format
  • Auto-Recognition of ID cards
Product Parameters
Specifications
  • Operating Voltage: DC 12-24V; Operating Current ≤35mA
  • Reading Distance: 3-6CM
  • Transmit Format: 4-6 digits key press, 4 bits or 8 bits data
  • ID Card Type: 125KHz, EM
  • Wiegand Format: Wiegand 26-37
  • Temperature: -40ºC to 60ºC
  • Humidity: 0~95% (non-condensing)
  • Dimensions: 158.6L x 43W x 21.7D (mm)
  • Weight: 0.5Kg
Product Showcase
Access Control Detail
Tuya Access Control View 1 Tuya Access Control View 2 Tuya Access Control View 3 Tuya Access Control View 4 Tuya Access Control View 5
Related Products
Related Product 1 Related Product 2 Related Product 3 Related Product 4
Frequently Asked Questions
How many users can this access control system support?
The system supports up to 2000 users, each capable of having their own card and a 4-6 digit password.
Is the device suitable for outdoor installation?
Yes, it features an aluminum alloy structure and is fully potted to meet IP65/IP68 waterproof standards, making it ideal for outdoor use.
What is the required operating voltage?
The device operates on a wide voltage range from DC 12V to 24V.
Does it support remote control via smartphone?
Yes, this is a Tuya WiFi smart version, allowing for smart control through the compatible app.
Can the keypad backlight be adjusted?
Yes, the metal digital backlit keypad can be set to Normal ON, Normal OFF, or Human-Approach ON.
What types of cards are compatible with the reader?
It has a built-in 125KHz card reader compatible with EM and HID cards.
